A powerful desktop CPU, with 2nd gen AMD 3D V-Cache™ Technology for you to enjoy extreme performance for gaming, creating, streaming or any workload you choose.

Specification

Processor

• Model: AMD Ryzen™ 9 9900X3D
• Family: AMD Ryzen™
• Series: Ryzen™ 9000 Series
• Architecture: Zen 5
• Former Codename: Granite Ridge AM5
• Platform: Desktop
• Market Segment: Enthusiast Desktop

Performance

• CPU Cores: 12
• Threads: 24
• Base Clock: 4.4 GHz
• Max Boost Clock: Up to 5.5 GHz
• L1 Cache: 960 KB
• L2 Cache: 12 MB
• L3 Cache: 128 MB (3D V-Cache)
• Default TDP: 120W

Manufacturing Technology

• CPU Process: TSMC 4nm FinFET
• I/O Die Process: TSMC 6nm FinFET
• Package Die Count: 3

Platform & Overclocking

• Socket: AM5
• Supported Chipsets: A620, B650, B650E, B840, B850, X670, X670E, X870, X870E
• Unlocked for Overclocking: Yes
• AMD EXPO™ Memory Overclocking: Yes
• Precision Boost Overdrive: Yes
• Curve Optimizer: Yes
• AMD Ryzen™ Master Support: Yes
• CPU Boost Technology: Precision Boost 2

Memory Support

• Memory Type: DDR5 UDIMM
• Memory Channels: 2
• Maximum Memory Capacity: 256 GB
• Memory Speed Support:
  • 2x1R: DDR5-5600
  • 2x2R: DDR5-5600
  • 4x1R: DDR5-3600
  • 4x2R: DDR5-3600
• ECC Support: Yes (Motherboard Dependent)

Connectivity & Expansion

• PCIe Version: PCIe® 5.0
• Native PCIe Lanes (Total / Usable): 28 / 24
• Native USB4 (40Gbps): 4
• Native USB 3.2 Gen 1 (5Gbps): 1
• NVMe Support: Boot, RAID 0, RAID 1, RAID 5, RAID 10

Integrated Graphics

• Graphics Model: AMD Radeon™ Graphics
• Graphics Cores: 2
• Graphics Frequency: 2200 MHz
• USB Type-C® DisplayPort™ Alternate Mode: Supported

Thermal & Cooling

• Default TDP: 120W
• Maximum Operating Temperature (Tjmax): 95°C
• Recommended Cooler: Liquid Cooler
• Thermal Solution Included: No

Operating System Support

• Windows 11 (64-bit)
• Windows 10 (64-bit)
• Ubuntu x86 64-bit
• RHEL x86 64-bit

Supported Technologies

• AMD EXPO™ Technology
• AMD Ryzen™ Technologies
