Mercusys MS110CMP 8-Port 10/100 Mbps + 2-Port Gigabit Desktop Switch with 8-Port PoE+, Black

Quick Overview

10 Ports: 8× 10/100 Mbps PoE+ Ports + 2× Gigabit non-PoE Ports
Two Cables in One: With 8 PoE+ ports, transfers data and power on one single cable
High Power PoE+: Support PoE Power up to 30 W for each PoE port and 115 W for all PoE ports*
2× Uplink Ports: MS110CMP provides 2× uplink ports when turning on the isolation mode. One for connecting to the Internet and one for connecting to the NVR.
Long-Range up to 250 m: Increases PoE transmission distance to 250 m by Extend Mode**
Isolation Mode: One click to divide traffic for specific ports for stability and security
Compliant with Powered Devices: Works with IEEE 802.3af/at compliant PDs
Plug and Play: Simple to use and saves time and effort
PoE Auto Recovery: Automatically reboots your dropped or unresponsive PoE-powered devices
Durable Metal Casing: Allows for efficient heat dissipation and long network life

SKU: MS110CMP Categories: Networking & Servers, Switches

Original price was: AED 199.00.Current price is: AED 125.00.

Warranty

Included Warranty	1 Year Free Warranty

Delivery

Standard Delivery	One Day Delivery

4 Items sold in last 24 hours

12 People watching this product now!

Description
Additional information

8-Port 10/100Mbps +2-Port Gigabit DesktopSwitch with 8-Port PoE+

MS110CMP

115W

PoE Budget

8×

PoE+ Ports

2×

Gigabit Ports

Plug and Play

Long-Range up to 250 m

Isolation Mode

PoE Auto Recovery

Silent Operation

Durable Metal Casing

8 PoE+ Ports and 2 Gigabit Ports for Network Deployment

Compliant with the 802.3af/at Powered Devices, each of the 8 PoE+ ports supports a maximum power supply of 30 W. 2 Gigabit non-PoE ports are for uplink devices, one of which is used to connect to the internet and the other to the NVR. The total 115 W PoE power budget* can be applied in various scenarios, including surveillance, offices, dormitories, and small businesses, since MS110CMP is compatible with devices such as IP cameras, access points, IP phones, PCs, video recorders, and etc.

30W

Max onEach Port

115W

Total PowerBudget

IP Camera

IP Phone

Access Point

Data and Power

Data Only

8 PoE+ Ports and 2 Gigabit Ports for Network Deployment

Gigabit ×2

INTERNET

Router

Network Video Recorder

Data and Power

Data Only

Power over Ethernet: Two Cables in One

Traditional Switches

Power

Data

MS110CMP

Power + Data

No Fuss

No need for electricians; simplify installation and deployment.

Cost-Efficiency

Getting rid of extra cables and power adapters will save money on infrastructure.

Flexibility

Deployment in complex situations is made possible by more placement possibilities.

Power Management

Improves power usage while intelligently protecting your gadgets from power surges.

IEEE 802.3af/at

PoE ports compliant with the 802.3af/at Powered Devices.

Long-Range up to 250 m with Extend Mode**

Extend Mode** increases PoE transmission distance to 250 m. MS110CMP has four long-range ports with PoE+. Turn on the Extend Mode and make it ideal for installing surveillance cameras over wide areas.

250m

Traffic Separation

With only one click, isolation mode divides traffic for ports 1-8 to prevent snooping/tampering and isolate broadcast storms for greater protection. MS110CMP provides 2× uplink ports when turning on the isolation mode.

PoE Auto Recovery

IP Camera

PoE Auto Recovery

The switch continuously detects data transmission with PoE-powered devices (PD). When a PD stops sending data packets to the switch for an extended length of time, the switch will reboot it automatically.

MDI

auto

MDIX

Plug and Play

MS110CMP offers auto-negotiation(10/100M) and automated MDl/MDIX. There is no additional configuration needed. lt is simple to use, saving time and effort.

Durable and Silent

MS110CMP’s durable metal case allows for efficient heat dissipation, excellent signal interference prevention, reliable equipment stability, and a long network life.

Specification

Standards and Protocols	IEEE 802.3x Flow Control
PoE Ports	RJ45 Standard: Compliant with 802.3 af/at Powered DevicesPoE Ports: Port 1- Port 8PoE Power Budget: 115 W
Dimensions	6.7 × 3.9 × 1.1 in (171 × 98 × 27 mm)
Interfaces	8× 10/100 Mbps Ports + 2× Gigabit Ports, Auto-Negotiation, Auto MDI/MDIX
External Power Supply	External Power Adapter (Output: 54V/2.2A)
Installation	Desktop / Wall Mount
Data Rates	10/100 Mbps at Half Duplex20/200 Mbps at Full Duplex
Jumbo Frame	2 KB
Switching Capacity	5.6 Gbps
MAC Address Table	2K
Max Power Consumption	3.79W（220 V / 50 Hz, no PD connected） 130.49W（220 V / 50 Hz, with 115W PD connected
Max Heat Dissipation	12.92 BTH/h （no PD connected) 444.97 BTH/h（with 115W PD connected）

Package Contents	• 10-Port 10/100Mbps Desktop Switch with 8-Port PoE+ (MS110CMP)• Power Adapter• Quick Installation Guide
Environment	Operating Temperature: -10℃~40℃ (14℉~104℉)Storage Temperature: -40℃~70℃ (-40℉~158℉)Operating Humidity: 10%~90% RH non-condensingStorage Humidity: 5%~95% RH non-condensing
