Samsung WAD Android OS Interactive Display, 86″ 4K UHD IPS Touch Display, 60Hz Refresh Rate, 8ms Response Time, Black
Quick Overview
-
Diagonal Size: 86″
-
Panel Type: IPS
-
Resolution: 3,840 x 2,160
- Brightness : 400 cd/m² (nits)
Unlimited Learning Possibilities
Introducing the Interactive Display WAD series, for engaging educational experiences. Based on Android OS, it provides a familiar and intuitive user experience.Download apps through Google Play and use pre-installed apps like YouTube and Chrome to stay productive and open a new era of education.

An intuitive UX that fits your needs
Powered by Android™
The WAD series offers familiarity to its users. It’s compatible with other Android devices and provides a variety of widgets and an easily customizable homescreen. These features create more flexibility in building an environment that suits various learning needs.

Effortless access to Google services
EDLA Certification
With an EDLA certification, the WAD series supports a variety of Google services like Google Play and YouTube. This access to major educational apps like GoogleClassroom leads to increase efficiency and enhance communication with students.

Display multiple screens simultaneously
Easy Multitasking
Various screen modes, including split screen and multi-window, enable teachers to easily display information and multitask at the same time on the WAD series.This flexibility provides convenient access to all the screens required to create engaging learning environments.

Smart, wireless sharing on multiple devices
Powerful Screen Sharing
The WAD series supports screen mirroring for up to nine devices, increasing student engagement. This feature ensures every student is included and engaged ascontent can be shared on both the large display and individual devices. It can be used on iOS, Mac, Windows, Android, or Chrome OS.

Writing experience

Better interaction with best-in-class multi-touch
Multi-point touch
Multiple users can write on the whiteboard at the same time with the display’s advanced multi-touch capabilities.Up to 40 simultaneous touchpoints are possible, allowing large groups of students and teachers to collaborateand learn together in a fun and natural way.

Switch pens without changing settings
Dual Pen
The dual pen function enables the use of two different writing tools with no downtime. With the double-sided nibapplied, users can effortlessly switch between two different colors on the front and back side of the pen – withoutneeding to change the settings or interrupt the flow of the lesson.
Connectivity

Convenient connectivity with USB-C
3-in-1 USB-C port
Connectivity is enhanced with the 3-in-1 USB-C port, enabling screen mirroring, touch control and external devicecharging (max. 65W). Teachers can simply connect to the USB Type-C port, allowing them to deliver interactiveand engaging lessons without any hassle.

Accessible content for any class size
HDMI out
With the HDMI Out function, whiteboard screen content can be shared on a different and larger screen in theclassroom. This feature ensures teachers can provide a real-time, interactive experience for students who caneasily view the screen content regardless of where they sit in the classroom.
Use your favorite OS for the learning
OPS (Open Pluggable Specification)
The OPS slot in the WAD series can transform the interactive display into a Windows device, eliminating the needfor an extra PC or devices. Users will have access to all the features and functionalities they are familiar with froma standard computer, directly on the display.
Device Management Solution

Seamless management, efficient operations
Device Management Solution
The WAD series provides a device management solution* essential for advanced educational environments. This solution optimizes the remote management of whiteboard settings and applications, guaranteeing operationalefficiency and stability.

Reduce eye strain with better eyecare settings
TUV Certification
The WAD series is equipped with features to protect users’ eye health. The anti-glare panel, low blue light, and flicker-free functions effectively block blue light and flicker while also diffusing reflection. The WAD series prevents glare even in bright settings.

Seamless learning in various environment
Superior Durability
The WAD series protects against electrical surges by using a ceramic fuse and 500V(DC) capacitor that absorbs instant spikes in voltage. It is also a valuable tool for schools in high humidity or rainy climates with anti-humidity glue applied to the critical areas of the chipset.

Specifications
Display
-
Diagonal Size: 86″
-
Panel Type: IPS
-
Resolution: 3,840 x 2,160
-
Pixel Pitch (HxV): 429.6 x 429.6 μm
-
Brightness (Typical): 400 nit
-
Contrast Ratio: 1,200:1
-
Viewing Angle (H/V): 178° / 178°
-
Response Time: 8 ms
-
Colour Gamut: 72%
-
Glass Haze: 25%
-
H-Scanning Frequency: 135 kHz
-
Maximum Pixel Frequency: 78 MHz
-
V-Scanning Frequency: 60 Hz
-
Operation Time Support: 12/7
Connectivity
-
HDMI In: 3 (Version 2)
-
HDCP Version: 2.1
-
USB: 5 (1×2.0, 4×3.0)
-
IR In: Yes
-
Audio In: Stereo Mini Jack
-
Audio Out: Stereo Mini Jack
-
Video Out: Yes
-
RS232 In/Out: Yes
-
RJ45 In/Out: Yes
-
WiFi: Yes
-
Bluetooth: Yes
Power
-
Power Supply: AC 100–240 V, 50/60 Hz
-
Power Consumption (On Mode): 486 W
-
Power Consumption (Sleep Mode): 0.5 W
Dimensions & Weight
-
Set Dimensions (WxHxD): 1957 x 1160 x 99 mm
-
Package Dimensions (WxHxD): 2110 x 1283 x 225 mm
-
Set Weight with Stand: 56.5 kg
-
Package Weight: 74.3 kg
Operation Conditions
-
Temperature: 0°C–40°C
-
Humidity: 10–90%
Mechanical Specifications
-
VESA Mount: 800 x 600 mm
-
Bezel Width: 16.4 mm (Top/Left/Right), 44.9 mm (Bottom)
-
Bezel Color: Space Gray
-
Frame Material: Non-Glossy
Optional Features
-
Touch: Yes (IR technology)
SoC
-
OS Version: Android 13
-
Flash Memory Size: 64 GB
Certification and Compliance
-
EMC: Part 15, Subpart B Class A, various standards
-
Safety: IEC 62368-1, IEC 60950-1, various standards
| Weight | 74.3 kg |
|---|---|
| Dimensions | 211 × 128.3 × 22.5 cm |
| Included Warranty | 1 Year Free Warranty |
| Standard Delivery | One Day Delivery |
