Specification

Display & Design

• Screen Size: 86-inch

• Resolution: 4K UHD

• Backlight: D-LED

• Brightness:

  • 350 cd/m² (HarmonyOS)

  • 450 cd/m² (Windows via OPS)

• Latency: 16 ms

• Touch Precision: ≤ 1.5 mm sensing distance

Dimensions (H × W × D):
1200.0 × 1953.0 × 91.8 mm

Weight:

• Net: 64.4 kg

• Gross: 78.4 kg

System & Performance

• Operating System: HarmonyOS

• Windows supported via optional OPS module

• Processor: 8-core CPU

• Memory: 8 GB RAM

• Storage: 128 GB Flash

Camera & AI Conferencing

• Camera Resolution: 4K

• Zoom: 5×

• Lens Setup:

  • 1× Wide-angle lens

  • 1× Telephoto lens

Audio System

• Microphones: 24-microphone array with AGC

• Speakers:

  • 2× Tweeters

  • 2× Full-range drivers

  • 1× Woofer

• Total Output Power: 70W

Connectivity & Wireless

• Wi-Fi: Dual-band (2.4 GHz + 5 GHz)

• Bluetooth: Yes

• NFC: Yes

• Ethernet: RJ45 (10/100/1000 Mbps)

Ports & Interfaces

Front Ports

• 2× USB Type-C

• 2× USB 3.0

Side Ports

• 2× HDMI IN

• 1× HDMI OUT

• 1× HDMI-AI

• 1× USB 3.0

• 1× Type-C (fast charging)

• 1× RJ45

• 1× TOUCH port

• 1× COM port

• 1× 3.5mm Line In

• 1× 3.5mm Line Out

Ideal For

• Large boardrooms

• Training centers

• Auditoriums

• Hybrid enterprise collaboration

• Executive presentation environments
