• 10-point capacitive touch, suitable for installing self ordering or navigation applications, facilitating self-service operation.
• Metal shell appearance, slim frame, and all-in-one design, suitable for advertising display at store entrances.
• Exquisite image, industrial A+ panel, auto-coloring and image-enhancing engine.
• Frosted glass, anti-glare, clearer images, and wider viewing angles.
• Variable materials, static and dynamic materials, including pictures, audio, video, scrolling subtitle, PDF, webpages, live video, number calling, pop-up pictures, etc.
• Flexible program schedule, free schedules and district play of multiple materials and variable play modes: play by day, play by week, play by loop, custom play, etc.
• Centralized management, remotely control and manage one screen or more screens, such as timed startup/shutdown, quick startup/shutdown, brightness/volume timed adjustment, and screenshot preview, remotely release programs and updates local (USB) programs.
• Organization permission, 5-level organization is available for managing materials, programs, terminals, and users, and support creating custom users, allocating permission for users according to user level, and permission templates.
• Multiple security safeguards, 3-level check of materials, programs and schedules to prevent mistake release, encryption of data in storage and transmission to prevent data tampering, and with no default password, users can activate and set initial password to guarantee the password safety

Specification

Product Model

• Model: DS-D6055UT-D/S

Display

• Screen Size: 55 inch
• Resolution: 2160 × 3840 (4K UHD)
• Panel Type: IPS
• Viewing Angle: 178° (H) / 178° (V)
• Active Display Area: 1209.6 (H) × 680.4 (V) mm
• Pixel Pitch: 0.315 (H) × 0.315 (V) mm
• Backlight: E-LED
• Brightness: 500 cd/m²
• Contrast Ratio: 1200:1
• Color Depth: 10-bit (8-bit + FRC)
• Color Gamut: 72% NTSC
• Response Time: 8 ms
• Refresh Rate: 60 Hz
• Color Temperature: 10000K
• Haze: 25%
• Display Ratio: 9:16 (Portrait)
• Reliability: 7 × 24 hours operation

Touch

• Touch Type: Capacitive (G+G)
• Touch Points: 10-point multi-touch
• Response Time: < 25 ms
• Precision: ± 2 mm

Built-in System

• Operating System: Android 13
• Processor: Cortex-A55, Quad-core, 1.92 GHz
• Memory: 4 GB RAM
• Storage: 32 GB eMMC

Supported Formats

• Video: AV1, H.265, H.264/AVC, MVC, VP9, AVS2, MPEG4, MPEG2, MPEG1, VP8, MJPEG, H263
• Audio: MPEG, APE, FLAC, AAC, OGG, AIF, AIFF, ALAW, ALAC

Connectivity & Interfaces

Input

• 1 × HDMI 2.0 (HDCP 2.2)

Output

• 2 × Speakers (8Ω, 5W each)

Network & Control

• 1 × RJ45 (LAN)
• Wi-Fi (2.4G/5G, 802.11 a/b/g/n/ac/ax)
• 1 × RS232 In
• 1 × RS232 Out

Data Ports

• 1 × USB 2.0
• 1 × USB 3.0
• Bluetooth 5.4

Power

• Input Voltage: 100–240V AC, 50/60 Hz
• Power Consumption: 108W (Typical), 155W (Max)
• Standby Consumption: ≤ 0.5W

Working Environment

• Operating Temperature: 0°C to 40°C
• Operating Humidity: 10% to 80% RH
• Storage Temperature: -20°C to 60°C
• Storage Humidity: 10% to 90% RH

Physical Specifications

• Mounting Type: Floor Standing

Dimensions (W × H × D)

• With Stand: 740 × 1886 × 480 mm
• Without Stand: 727 × 1776 × 63.8 mm
• Package Dimensions: 840 × 1895 × 155 mm
• Net Weight: 46.5 kg
• Gross Weight: 52 kg
