Use Logitech Sync with Rally Plus when it is paired with RoomMate; monitor room and device health, deploy updates, and modify settings.

ENSURE BUSINESS CONTINUITY WITH SELECT SERVICE PLAN

Remove barriers to collaboration and ensure conference rooms are ready for the next meeting. Select is a service plan beneficial for all room sizes and deployments. Optimize uptime with expert assistance within one hour, get fast product replacements, and take advantage of premium Sync functionality to proactively resolve issues before they impact your business. When you choose Select, we partner with you to reduce daily management, optimize performance, and help you maximize your investment.

Specification

Dimensions

Rally Camera

• Height: 182.5 mm
• Width: 152 mm
• Depth: 152 mm

Rally Speaker

• Height: 103 mm
• Width: 449 mm
• Depth: 80 mm

Rally Mic Pod

• Height: 21 mm
• Width: 102 mm
• Depth: 102 mm

Rally Display Hub

• Height: 40 mm
• Width: 206 mm
• Depth: 179 mm

Rally Table Hub

• Height: 40 mm
• Width: 176 mm
• Depth: 138 mm

RightSense™ Technologies

RightLight™ (WDR)

• Low-light compensation
• Video noise reduction
• Optimized color saturation
• Natural skin tone rendering
• Reduces glare and backlighting

RightSight™

• Human figure detection
• Auto-framing at meeting start
• On-demand and continuous auto-reframing

RightSound™

• AI-based speech enhancement
• Acoustic Echo Cancellation (AEC)
• Voice Activity Detection (VAD)
• Background noise suppression
• Auto-leveling of voices

RightSound Mic Matrix

• Beamforming with up to 56 acoustic beams
• Focus refresh rate: 8 ms (125 times/sec)
• Precision voice targeting

Anti-Vibration System

• Reduces vibration from speakers
• Improves echo cancellation
• Ensures stable video even at high volume

Rally Camera

• Zoom: 15x HD (5x optical + 3x digital)
• Pan: ±90° (180° total)
• Tilt: +50° / -90° (140° total)
• Field of View:
  • Diagonal: 90°
  • Horizontal: 82°
  • Vertical: 52°
• Total coverage: 262° wide × 192° tall
• Resolution:
  • 4K Ultra HD @ 30fps
  • 1440p, 1080p, 900p, 720p, SD
  • 1080p & 720p @ 60fps
• RightLight (WDR + low-light optimization)
• Privacy mode: lens parks at -90°

Rally Mic Pod

• Pickup range: 7 m diameter
• 4 omnidirectional microphones → 8 acoustic beams
• AEC, VAD, noise suppression
• Frequency response: 90 Hz – 16 kHz
• Sensitivity: > -27 dB ±1 dB
• Data rate: 48 kHz
• Daisy-chain up to 7 mic pods

Room Capacity

• 1 Mic Pod: up to 16 participants
• Additional: +6 participants per mic
• Max setup (7 pods): up to 46 participants

Rally Speaker

• 76 mm high-performance driver
• Anti-vibration suspension system
• Volume:
  • 95 dB SPL @1W
  • 100 dB SPL @7.5W
• Low distortion audio
• Sampling rate: 48 kHz

Rally Table Hub

• CAT6A connection to Display Hub (up to 50 m)
• Active speaker detection (56 beams every 8 ms)
• Ports:
  • HDMI (x2 passthrough)
  • USB-C
  • USB-A (reserved)
  • USB-B (PC connection)
  • RJ45 (reserved)
  • 12-pin Mic Pod connector

Rally Display Hub

• HDMI outputs (x2) to displays
• USB-C (camera connection)
• USB-B (PC connection)
• RJ45 (Table Hub link)
• Mini XLR (x2 for speakers)
• Powers up to 2 speakers

Remote Control

• RF remote (no line-of-sight required)
• CR2032 battery included

Cables & Power

• Camera ↔ Display Hub: USB-C (2 m)
• PC ↔ Hub: USB-A to USB-B (2 m)
• Display Hub ↔ Table Hub: CAT6A (5 m, up to 50 m supported)
• Speaker: Mini XLR (2.95 m)
• HDMI cables (2 m)
• Power cables included

Accessories

• Rally Mounting Kit (camera, speakers, hubs)
• Rally Mic Pods (up to 7)
• Mic Pod Mount (cable management)
• Mic Pod Hub (flexible placement)
• Additional Rally Speaker

Compatibility & Deployment

• Plug-and-play USB connectivity
• Works with major video conferencing platforms
• Appliance mode supported with Logitech RoomMate
