Introducing Rally Board 65

Learn how Rally Board 65 is purpose-built to provide intelligent video and audio for meeting rooms, open spaces, and satellite offices.

Simple all-in-one solution

Everything you need to quickly add video to meeting rooms and open spaces. Experience all-in-one video conferencing that combines crystal clear video, powerful audio, and AI-driven features, all integrated into a single 65-inch touchscreen.

BUILT FOR FLEXIBILITY

Rally Board 65 is designed for the way you meet. It can be deployed with the camera positioned above or below the screen, ensuring all participants maintain natural eye contact in any space.

READY IN NO TIME

Set up right out of the box in just a few steps and minimize the need for onsite IT support. Included mounts and remote configuration mean you can get Rally Board 65 up and running in minutes.

Everyone is clearly seen and heard

Make sure everyone is seen and heard in meeting rooms and open spaces. AI-driven video and audio technologies — RightSight 2 and RightSound 2 — ensure optimal framing and clear sound for every participant.

DEPTH BLUR

Provides clear focus and helps eliminate distractions by using a depth-mapping sensor to distinguish between in-focus and out-of-focus areas, delivering a more natural depth effect compared to standard background blur settings

RightSight 2

Optimize participant framing and image processing to deliver clear, crisp visuals for more productive person-to-person interactions.

Specification

Dimensions

Logitech Rally Board 65 (Device Only)

• Width: 1500 mm
• Height: 989 mm
• Depth: 76 mm
• Weight: 46 kg
• VESA standard: MIS F (400 × 400 mm and 400 × 200 mm)

Rally Board 65 with Included Table Stand

• Width: 1500 mm
• Height: 1051 mm
• Depth: 395 mm
• Weight: 50 kg

General

• Built-in front microphone array
• Digital PTZ camera
• Dual full-range ported speakers and dual tweeters
• Ultrasonic emitter
• Cable management and retention system
• Integrated motorized privacy shutter
• Depth mapping camera
• Radar motion sensing
• Environmental sensors
• Supports second display up to UHD 4K60
• HDMI ingest up to 4K60
• IPv4 and IPv6 support
• Proxy support:
  • IP-based proxy
  • FQDN-based proxy
  • PAC file proxy

System Requirements

• Power: 100–240V
• Internet connection: Wired or wireless
• Room solution software license required (sold separately)

Display

• 65-inch LCD touchscreen
• IR touch technology with 20 touch points
• UHD 4K resolution (3840 × 2160)
• 16:9 aspect ratio
• Anti-glare coating
• Anti-fingerprint coating
• Contrast ratio: 5000:1
• Brightness: 400 nits

Camera

Main Camera

• 1-inch 20.3 MP imaging sensor
• Resolutions:
  • 4K
  • 1440p
  • 1080p
  • 900p
  • 720p
  • SD at 30 fps
• Automatic motorized tilt
• 4× HD digital zoom

Field of View

• Diagonal: 115.7°
• Horizontal: 103.3°
• Vertical: 60.7°

Depth Mapping Camera

• Diagonal FOV: 145°
• Horizontal FOV: 121°

Speakers

Dual Full-Range Ported Speakers

• Driver: 2 × 70 mm
• Sensitivity: 89 dB SPL
• Rated power: 8W
• THD at 1W, 1 kHz: <2%

Dual Tweeters

• Driver: 2 × 31 mm
• Sensitivity: 93 dB SPL
• Rated power: 8W
• THD at 1W, 4 kHz: <2%

Microphones

Front Microphone Array

• Frequency response: 90Hz–16KHz
• Sensitivity: -36 dB FS ±1 dB @ 1 Pa
• Output data rate: 48KHz
• Pickup range: Up to 7 m

RightSound 2 Features

• AI speech enhancement
• AI beamforming and beam selection
• AI speech detection
• AI direction of speech
• Acoustic echo cancellation
• Residual echo suppression

Sensors

• Temperature
• Humidity
• Total VOC (tVOC)
• Carbon dioxide
• PM2.5
• PM10
• Radar
• Ambient light

Interfaces

• HDMI Out: 1 × up to 4K60
• HDMI In: 1 × up to 4K60
• USB-A: 3 × USB 3.1
• USB-C: 1 × USB 3.1 Type-C with DP Alt Mode
• 3.5 mm line-out audio
• Ethernet: 10/100/1G
• Wi-Fi: 802.11a/b/g/n/ac/ax
• Bluetooth Low Energy
• RJ45 EXT port (reserved for future use)

Power & Environmental

Power

• Built-in auto-sensing 100–240V power supply
• AC cable length: 3 m

Environmental Conditions

• Operating temperature: 0–35 °C
• Storage temperature: -40–60 °C
• Humidity: 10–95%

Security

• AES-256 file encryption
• Symmetric key and PKI data encryption
• Device attestation protection
• API-authenticated device access
• Arm TrustZone and RPMB key protection

Accessories

• Rally Board 65 Cart
• Active USB Cable

Included in the Box

• Main device
• Tabletop legs (x2)
• Power cord
• Stylus (x2)
• VESA 100 PC mount
• Cable hook
• Assembly hardware and tools
• Documentation
