Dell Pro 27 Plus QHD USB-C Hub – P2725DE Monitors, 2560 x 1440 Resolution, 100Hz Refresh Rate, 5ms GtG Fast Response Time, Black

SPECIFICATIONS

Technical Information

• Number of Screens: 1
• Screen Size Class: 27″
• Viewable Screen Size: 27″
• Screen Mode: WQHD
• Panel Technology: In-plane Switching (IPS) Technology

• Response Time Details
– 5ms GTG (Fast)
– 8ms GTG

• Display
– Aspect Ratio: 16:9
– Pixel Pitch: 0.2331 mm x 0.2331 mm
– Horizontal Viewing Angle: 178°
– Vertical Viewing Angle: 178°
– Mount Type: Panel Mount
– Backlight Technology: LED Edgelight System
– HDCP Supported: Yes
– Glass Hardness: 3H
– Operation Hours: 8 Hours/5 Days

• Adjustability
– Maximum Adjustable Height: 15.01 cm
– Tilt Angle: -5° to 21°
– Swivel Angle: -45° to 45°
– Pivot Angle: +/-90°
– Adjustable Stand: Yes
– Stand Adjustments
– Tilt
– Pivot
– Height
– Swivel
– Stand Included: Yes

• Features
– Narrow Bezel
– Mercury-free
– Arsenic-free Glass
– sRGB
– Eye Comfort Technology
– PVC Free
– BFR Free
– Stand Lock
– Cable Lock Slot
– Security Lock
– Anti-glare

• Horizontal Frequency
– 30 kHz to 151 kHz – DisplayPort
– 30 kHz to 151 kHz – HDMI
– 30 kHz to 151 kHz – USB Type C

• Vertical Frequency
– 48 Hz to 100 Hz – DisplayPort
– 48 Hz to 100 Hz – HDMI
– 48 Hz to 100 Hz – USB Type C

Video

• Maximum Resolution: 2560 x 1440
• Standard Refresh Rate: 100 Hz
• Color Supported: 16.7 Million Colors
• Native Contrast Ratio: 1,500:1
• Brightness: 350 cd/m2
• Color Gamut: 99% sRGB (CIE 1931)
• Maximum Preset Resolution: 2560 x 1440 at 100Hz
• Pixel Per Inch (PPI): 109

Interfaces/Ports

• Connectivity
– Video port
– 1 HDMI port (HDCP 1.4) (Supports up to QHD 2560 x 1440 100Hz TMDS as per specified in HDMI 2.1)
– 1 Display Port 1.4 (HDCP1.4)(Support up to 2560 x 1440 100Hz)
– 1 DisplayPort (out) port with MST (HDCP 1.4)

– USB port
– 1 USB-C 5Gbps upstream port (DisplayPort 1.4 Alternate mode, Power Delivery up to 90W)
– 1 USB-C 5Gbps downstream port
– 3 USB 5Gbps Type-A downstream ports

– Ethernet port
– 1 RJ45

• USB Type-C (Power Delivery): 90 W

Built-in Devices

• Built-in Devices: NA

Environmental Conditions

• Operating Temperature Range: 32°F (0°C) to 104°F (40°C)
• Non-operating Temperature Range: -4°F (-20°C) to 140°F (60°C)
• Operating Humidity Range: 10% to 80% (Non-condensing)
• Non-operating Humidity Range: 5% to 90% (Non-condensing)
• Maximum Operating Altitude: 16404 ft
• Maximum Non-operating Altitude: 40000 ft

Power Description

• Input Voltage Range: 100V AC to 240V AC
• Operating Power Consumption: 19.60 W
• Standby Power Consumption: 0.30 W
• Off-Mode Power Consumption: 0.30 W
• Frequency: 60 Hz; 50 Hz
• Maximum Power Consumption: 200 W
• Voltage Current: 3.0 A

Physical Characteristics

• VESA Mount Compatible: Yes
• VESA Mount Standard: 100 x 100

• Dimensions
– Without stand: Width 61.24 cm x Height 35.66 cm x Depth 5.00 cm
– With stand: Width 61.24 cm x Height 53.57 cm x Depth 19.23 cm

• Height with Stand
– Compressed Height with Stand: 38.58 cm
– Extended Height with Stand: 53.57 cm

• Bezel Width
– Bezel Width (Top): 0.79 cm
– Bezel Width (Bottom): 1.30 cm
– Bezel Width (Left): 0.79 cm
– Bezel Width (Right): 0.79 cm

• Stand Dimensions
– Stand Height: 42.82 cm
– Stand Width: 27.28 cm
– Stand Depth: 18.90 cm

• Weight
– Weight (Approximate): 4.60 kg
– Weight with Stand (Approximate): 6.59 kg

Miscellaneous

• Package Contents
– Pro 27 Plus QHD USB-C Hub Monitor P2725DE
– Stand

• Cable Type Included
– Power cable
– 1 x DisplayPort to DisplayPort 1.4 cable – 1.80 m
– 1 x USB-C to C 10Gbps, 100W cable – 1.00 m
– 1 x USB Type-C to Type-A 5Gbps cable – 1.80 m

• Energy Star: Yes
• Country of Origin: China
• TCO Certified: Yes
• Dell Display Manager Compatibility: Yes
• Remote Asset Management: DDPM
• Environmentally Friendly: Yes

• Environmental Certification
– TCO Certified 10.0
– TCO Certified Edge
– Electronic Product Environmental Assessment Tool Climate+ (EPEAT Climate+)
– Electronic Product Environmental Assessment Tool Gold (EPEAT Gold)

• Energy Efficiency Certification: ENERGY STAR 8.0
• Energy Efficiency Compliance: Energy-related Products Directive Lot 5 (ErP Lot 5)
• Environmental Compliance: Restriction of Hazardous Substances (RoHS)
