Scan and automatically save documents with barcode to the designated location in your network with Barcode Utility.

Specification

Performance

• Scanning Speed:

  • 30 ppm @ 300 dpi

  • 7 ppm @ 600 dpi

• Scan Mode: Colour & Monochrome

• Duplex Scanning: Yes (Automatic 2-Sided)

• ADF Capacity: Up to 20 Sheets

• Memory: 512MB SDRAM

Supported Document Size

Multiple Sheets (ADF):

• Width: 50.8 mm – 215.9 mm

• Length: 70 mm – 355.6 mm

Maximum Scan Width:

• Up to 215.9 mm

Scan Quality

• Optical Resolution: Up to 600 × 600 dpi

• Interpolated Resolution: Up to 1200 × 1200 dpi

• Input Colour Depth: 48-bit Colour Processing

• Output Colour Depth: 24-bit Colour Processing

Network & Connectivity

• Wireless Security:

  • WEP 64/128-bit

  • WPA-PSK (TKIP/AES)

  • WPA2-PSK (TKIP/AES)

  • WPA3-SAE (AES)

• Easy Setup: WPS Supported

Ideal for small offices and shared workspaces with secure wireless scanning.

Physical Specifications

• Dimensions (W × D × H): 288 × 101 × 85 mm

• Weight: 1.37 kg

Compact and lightweight – suitable for desk setups and portable use.

Power & Operating Conditions

Power Source:

• AC Adapter: 100–240V AC, 50/60 Hz

• DC: 5V, 3A

• Operating Temperature: 5°C – 35°C

• Operating Humidity: 20% – 80%

• Storage Humidity: 10% – 90%

OS Compatibility

Windows (TWAIN & WIA Compliant):

• Windows 10

• Windows 11
